Core Pins
Meaning
Cylindrical steel inserts used within an injection mould form the internal geometry of a hollow part or create specific through holes. These core pins extend from the mould face into the cavity and must withstand the high pressure of the incoming melt. Proper design ensures that the hollow features of the moulded part meet dimensional tolerances after the plastic shrinks during the cooling phase.
The application of these inserts is restricted to the creation of internal voids and does not include the forming of external part surfaces.
Cooling Channel
Internal cooling circuits often run through the center of the steel to manage the heat load in thick sections. Because plastic surrounds the metal on multiple sides, these areas act as heat sinks that can cause cycle time bottlenecks if not actively cooled, necessitating the use of baffles or bubblers to facilitate the flow of water into the deepest reaches of the pin. Rapid heat removal prevents the formation of sink marks or internal voids in the polymer.
Mechanical Stability
Lateral pressure from the flowing resin can cause slender inserts to bend or shift during the injection cycle. This deflection results in wall thickness variations and potential part rejection. Hardened tool steel provides the necessary stiffness to resist these forces.
Coating the surface with chrome or titanium nitride reduces friction and aids in the clean release of the part.
Maintenance Requirement
Regular inspection of the steel surface for signs of galling or thermal fatigue is required to prevent part defects. Small chips or scratches on the pin will be mirrored on the internal surface of every moulded part. Precision measurements verify that the pin has not experienced permanent deformation or thinning over thousands of cycles.
Replacing worn inserts before they fail avoids unplanned downtime and high scrap rates.
