Meaning
Bending stiffness of plastics measured under standardized three-point loading conditions provides a comparative baseline for resin selection. Flexural modulus ISO 178 specifies the method to determine the flexural properties of rigid and semi-rigid plastics. The test utilizes a rectangular bar supported on two edges and loaded at the center of the span.
Results from this procedure allow design engineers to calculate the wall thickness required for molded parts to resist bending.
Measurement Protocol
Test specimens are placed on a support span that is adjusted based on the thickness of the sample. A loading nose applies force at the center of the span at a constant deflection rate while sensors record force and deflection. The flexural modulus is calculated from the slope of the stress-strain curve in the initial elastic deformation region.
Variations in specimen thickness can introduce measurement errors because thickness holds a cubic relationship with bending resistance.
Processing Dependency
Injection molding parameters alter the measured stiffness by influencing the orientation of the polymer molecules and the degree of crystallinity. Rapid cooling freezes the molecules in a disorganized state, which reduces the modulus compared to a slowly cooled, highly crystalline part. Moulders can increase cavity pressure and melt temperature to adjust these morphological features.
Regrind additions also alter the stiffness by introducing shorter polymer chains that reduce the overall crystalline order.
Data Limitation
Short-term modulus values from laboratory tests do not account for long-term creep or elevated temperature environments. Designers must apply safety factors to these data sheet values when calculating load limits for continuous applications. This prevents sudden part collapse.
